Vertical Energy Recovery Ventilators
Short Description:
| Model: | ERVQ – L300 – 1A1FERVQ – L600 – 1A1F |
| Airflow: | 300m³/h ~ 600m³/h |
| Introduction: | |
| Certification: |
|
Main Feature of Vertical Energy Recovery Ventilators
Triple filtration
99% HEPA filtration
Slight positive indoor pressure
High efficiency energy recovery rate
Optional high efficiency fan with DC motors
Remote control
Colorful design
Visual management LCD display
Specifications of Vertical Energy Recovery Ventilators
| Model | ERVQ - L300 - 1A1F | ERVQ - L600 - 1A1F |
| Airflow (m3/h) | 300 | 600 |
| Filtration euiciency (%) | 99 % / HEPA | 99 % / HEPA |
| Filtration mode | Pm2.5 purify / Deep purify / Ultra purify | Pm2.5 purify / Deep purify / Ultra purify |
| Speed | DC / 8 speed | DC / 8 speed |
| Input power (W) | 70 | 125 |
| Temperture euiciency (%) | 0.82 | 0.82 |
| Noise dB(A) | 25 - 36 | 25 - 36 |
| Control | Touch screen panel / Remote control | Touch screen panel / Remote control |
| Air quality display | PM2.5 / Temp & R.H | PM2.5 / Temp & R.H |
| Operational Mode | Manual / Auto / Timer | Manual / Auto / Timer |
| Suitable room size (m2) | 50 - 120 | 100 - 240 |
| Dimension (mm) | 560*410*1580 | 560*460*1700 |
| Weight (kg) | 55 | 65 |
